45° Hose Barb Fittings Swivel Female Adapter 142
Industrial standard-use in all general purpose applications.
Material: Brass (Other materials available upon request), straight barstock & forged fittings.
Specification
Temp: From -40° to +160°F
Pressure Max:. at 150 PSI maximum.
Material: CA 360 Brass for Barstock fittings.,CA377 Brass for forged fittings
Typical Application:
Temperature control circuits,pneumatic circuits, vacuum and fluid systems
test apparatus, lubricant, coolant lines
Pressure:
Will withstand burst pressures of plastic tubing
Reference Part No:
142 - 201BF - FK-MS - KDS
PART# |
HOSE I.D×45° Flare |
C |
D |
M |
L |
142-3-4 |
3/16×1/4(7/16-20) |
7/16 |
.125 |
.75 |
1.50 |
142-4-4 |
1/4×1/4(7/16-20) |
7/16 |
.187 |
.97 | 1.72 |
142-4-6 |
1/4×3/8(5/8-18) |
5/8 |
.187 |
.97 | 1.82 |
142-5-5 |
5/16×5/16(1/2-20) |
1/2 |
.250 |
.97 |
1.75 |
142-6-6 |
3/8×3/8(5/8-18) |
5/8 |
.281 |
.97 |
1.82 |
142-6-8 |
3/8×1/2(3/4-16) |
3/4 |
.281 |
.97 | 1.97 |
142-8-8 |
1/2×1/2(3/4-16) |
3/4 |
.415 |
.97 |
1.97 |
we are professional China 45° Hose Barb Fittings Swivel Female Adapter Suppliers and Brass Fittings Manufacturers,we are offer45° Hose Barb Fittings Swivel Female Adapter...
